TPU Layflat Hose
Product specifications:
| Name | TPU Layflat Hose |
| Material | Inner layer: super wear-resistant TPU Reinforcement layer: high strength polyester filament Outer rubber layer: super wear-resistant TPU |
| Temperature range | - 50°C~+80°C (-58°F~+176°F) |
| Color | Red, blue, green, yellow, etc., colors can be customized. |
| Length | The length of a single hose is not limited and can be rolled flat. |
Application scope:
TPU layflathose is suitable for high-pressure mine drainage, irrigation, shale oil and gas drilling and fracturing water transportation, emergency water transportation for rescue and disaster relief, rapid fire water supply, river dredging projects, industrial wastewater transportation, etc.
Product specifications:
| Pipe diameter | Pipe wall thickness (mm) | Weight (kg/m) | Work pressure (BP) | Burst pressure (WP) |
| 4" (100mm) | 5.5 | 4.2 | 2.8MPa | 8.4MPa |
| 5" (125mm) | 3.5 | 3.8 | 1.5MPa | 4.5MPa |
| 6" (150mm) | 6.5 | 4.8 | 2.8MPa | 8.4MPa |
| 7" (175mm) | 4.0 | 3.8 | 1.5MPa | 4.5MPa |
| 8" (200mm) | 4.2 | 3.8 | 1.3MPa | 3.9MPa |
| 10" (250mm) | 4.8 | 4.5 | 1.3MPa | 3.9MPa |
| 12" (300mm) | 5.2 | 5.0 | 1.0MPa | 3.0MPa |
Features:
1. The TPU layflat hose is made of a 3-layer structure. Conductive metal wires are added to the middle fiber layer to solve the problem of static electricity generated by the hose during the oil transportation process, ensuring safe and efficient oil transportation.
2. The weight of TPU layflat hose is one-tenth that of traditional steel pipelines, and the length of a single hose is not limited. The hose is easy to transport and adapts to rapid response and emergency deployment in emergencies.
The tube wall of TPU layflat hose is soft and smooth, wear-resistant and corrosion-resistant, can be coiled and stored, has strong environmental adaptability, and smooth material transportation.
FAQ:
1. What is the length of each roll of your TPU layflat hose?
The standard length of layflat flat hose is 100m, we can also make any length according to customer's requirements.
2. What is the size range of TPU flat hoses that you can produce?
Minimum size is 3/4”-19mm, maximum size is 16”-406mm.
3. What is the working pressure of your TPU layflat hose?
Maximum working pressure is 10bar.
4. What is the service life of TPU flat hose?
If kept in good condition, the service life is 2-3
